2.1N 50mm Stroke Rectangular Voice Coil Linear Motor For Optical Focusing
Product Details
| Protect Feature | Totally Enclosed | Model Number | VCAS0002-0498-00A |
|---|---|---|---|
| Control Method | Electronic | Total Stroke | 49.8mm |
| Construction | Permanent Magnet | Peak Force | 2.1N |
| Size | 72*42.6*33mm | Keywords | Voice Coil Linear Motors |
| Voltage | 11.3V | Weight Of The Coil | 15g |
| Speed | High Speed (rpm) |
Product Description
Product Description:
SUPT MOTION’s VCAS0002-0498-00A is a compact rectangular voice-coil linear motor designed for short-stroke, low-thrust precision positioning. This moving-coil actuator delivers a peak thrust of 2.1 N and a total stroke of 50 mm, providing smooth, cogging-free linear motion. It is ideal for optical focusing, micro-valve control, and light-load XY positioning applications. Its low moving mass (coil weight of only 15 g) ensures high dynamic response and low power consumption. With a maximum operating voltage of just 11.3 V, it is easy to integrate into sensitive electronic systems.
Unlike traditional screw or belt drives, the VCAS series eliminates backlash and mechanical wear, significantly improving service life and positioning repeatability. Its rectangular design is particularly well-suited for space-constrained XY-stacked applications in semiconductor inspection or laser alignment modules.
Whether used in laboratory automation, autofocus modules, or active vibration isolation systems, the rectangular voice coil linear motor delivers direct-drive reliability within a compact footprint.
Features:
-
Peak Force: 2.1 N
-
Continuous Force @25℃: 1.3 N
-
Total Stroke: 50 mm
-
Max Voltage: 11.3 V
-
Back EMF Constant: 1.3 V/m/s
-
Coil Weight: 15 g
-
Dimensions (L×W×H): 72×42.6×33 mm
Product Parameters:
| Product Model | Peak Force (N) |
Continuous Force at 25℃(N) |
Total Stroke (mm) |
Max Voltage (V) |
Back EMF Constant (V/m/s) |
Weight of the coil (g) |
Length (mm) |
Width (mm) |
Height (mm) |
| VCAS0002-0498-00A | 2.1 | 1.3 | 50 | 11.3 | 1.3 | 15 | 72 | 42.6 | 33 |
| VCAS0002-0747-00A | 2.1 | 1.3 | 74.7 | 11.3 | 1.3 | 15 | 100.5 | 42.6 | 37 |
| VCAS0006-0030-00A | 6.1 | 3.2 | 3 | 13.3 | 4.6 | 18.2 | 25.1 | 34.1 | 27 |
| VCAS0006-0099-00A | 6.1 | 3.2 | 10 | 13.7 | 4.6 | 18.2 | 33.5 | 34.1 | 26.9 |
| VCAS0013-0343-00A | 13 | 8 | 34.3 | 12.6 | 5.8 | 40 | 68.3 | 60 | 34.8 |
| VCAS0065-1000-00A | 65 | 22.4 | 100 | 28.7 | 9.7 | 135 | 170 | 59.6 | 81.9 |
VCAS0002-0498-00A:
| Parameter | value | Parameter | value |
| Model | VCAS0002-0498-00A | Peak thrust | 2.1N |
| Continuous Thrust (25°C) | 1.3N | Total stroke | 49.8mm |
| Maximum Voltage | 11.3V | Back-EMF constant | 1.3V/m/s |
| Length | 72mm | Width | 42.6mm |
| Height | 33mm | Coil Weight | 15g |
Applications:
1.Auto-focus , zoom mechanisms
2.Micro valve control
3.Semiconductor alignment
4.Optical filter switching
5.Precision light-load XY stages
| The main application of a voice coil motor: | ||||||||||
| 1.Semiconductor industry:Wiring, cutting, drilling, transportation systems, welding, robotics. | ||||||||||
| 2.Valve operation in the field:Type metering valves, pressure test systems, pneumatic valve chemistry injection system. | ||||||||||
| 3.Micro Machine industry:Feed systems, micro drilling, precision stamping. | ||||||||||
| 4.Vibration System:Shaking table, vibration platform. | ||||||||||
| 5.Medical field:Micro-injection system, respiratory equipment, testing equipment. | ||||||||||
| 6.Aviation Technology:Flight control system, pilot feedback system. | ||||||||||
| 7.Commercial use field:Computer cooling pump miniature camera auto focus system. | ||||||||||
| 8.Automation industry:Laser equipment, dispenser, test equipment, textile machinery. |
